W&g ps-19 level generator
The Wandel & Goltermann PS-19 is a level sender for the frequency range 80 Hz to 25 MHz, which can be used together with the level meter SPM 19.
Crystal stabilized frequency setting by keyboard, in steps or continuously.
High frequency accuracy, max resolution 0.1 cycles per second.
Transmission levels in 0,1 railway-gradate adjustable, level announcement in railways, dB0 and/or dBm/dB0.
Exit coaxially and symmetrically.
Level generator from 80 Hz to 25 MHz (on coax output 75 ohm) and up 14 MHz balanced (124, 150 and 600 ohm).
Resolution 0.1 Hz and level inclusive from -75 dBm and +10 dBm (on 75 ohm)
This item is used and has been powered up, no further tests have been performed. Wear may be evident.
Local Pick up is also available at our office in Clayton South VIC 3169 with 24 Hrs Prior Notice.
