Fluke pm 2535 system multimeter 6.5 digit with gpib
Fluke PM 2535 System Multimeter 6.5 digit with GPIB interface
The PM2535 is a digital, automatic multimeter controlled by a microcomputer
* 6.5 to 3.5 digit display, depending on function and range
* DC Voltage 300mV, 3V, 30V, 300V
* AC Voltage True RMS, AC coupled 300mV, 3V, 30V, 300V
* AC Current, True RMS, AC coupled 30mA, 3A
* Resistance, in two-wire and four-wire configuration 3k, 30k, 300k, 3M, 30M and 300MOhm
* Temperature -100deg. to 850deg. C.
* Input of figures 0...9, polarity and decimal
* Extended capabilities via the IEC-625/IEEE-488 Interface (all manual controls are accessible)
* The PM2535 is equipped with an internal guard, which is externally accessible.
Very low noise voltages can be measured with high accuracy
* Ranges can be selected manually, automatically, or remotely
* User-alterable speed to increase number of measurements per second, or increase resolution
* Filter function switches in a frequency filter in AC voltage and current; in other modes besides temperature it acts as a digital filter
* Measurements can be started with internal, external or manual facilities, via trigger input or remote communications.
* Help functions are as follows:
* Mathematical functions, such as AX+B, delta%, dBm, ZERO
* Aquisition/presentation of the measuring data, such as: DELAY, LIMITS, BURST, RD.BUF, MIN/MAX, DIGITS
* Function Programming: call and store combinations of instrument settings. PROG and SEQU
* General: Beeper on/off, CHECK, ENTER, CLEAR
* Satisfies EEC Directive 73/23, conforming with IEC publication 348
