Hp agilent 6632A power supply, 20V, 5A 100W
HP Agilent 6632A Power Supply, 0-20V, 0-5A, 100W
* Description: The HP Agilent 6632A is a 100W, single output, series pass regulated power supply optimized for systems applications and is fully programmable via HPIB. The HP 6632A allows both the voltage and the current output to be programmed for either CV or CC operation. A built in DVM and precision current shunt measure (readback) the actual power supply output. The HP 6632A not only will source current, but will also sink as well. This provides very fast down programming speeds throughput in production test applications. The negative current setting tracks the user programmed positive current (CC) setting. Remote sense terminals allow for precise voltage regulation at the load. This feature will compensate for load lead IR drops of up to 2 volts per lead. The HP 6632A Power Supply also features overvoltage and overcurrent protection, selftest capability, software calibration, Fast and Normal operating modes, and with option 760, Isolation, Polarity Reversal Relay and Discrete Fault Indicator and Remote Inhibit lines along with a quick disconnect DC output terminal connector. Specifications of the HP Agilent 6632A include:
* Load Effect (Load Regulation): For a load charge from zero to maximum rated voltage or current of the suply
* Source Effect (Line Regulation): Given for any change within the rated line voltage for any ouput within the rated ouput voltage, currrent, and power of the supply
* Programming accuracy at 25°C ±5°C (% of setting plus fixed)
* Voltage Resolution / Voltage Accuracy: 5 mV / 0.05% + 10 mV
* + Current Resolution / Current Accuracy: 1.25 mA / 0.15% + 7 mA
* PARD (Ripple & Noise) (20 Hz to 20 MHz)
* Voltage (normal): 0.3 mV/3mV
* Voltage (fast): 1 mV/10 mV
* Drift (Stability): Change in output over 8-hour interval under constant line, load, and ambient temperature following 30-minute warm-up
* Voltage: 0.01% + 0.5 mV
* Voltmeter: (25°C ±5°C) Refers to data read back to the controller from the HPIB and as viewed via the front panel display
* Accuracy: 0.07% + 15 mV
* Ammeter: (25°C ±5°C) Refers to data read back to the controller from the HPIB and as viewed via the front panel display
* Accuracy: 0.18% + 9 mA
* DC Output Isolation: Maximum voltage either output terminal (+/-) may be from chasis ground: +/- 240 VDC
* Remote Sensing: Maximum allowable voltage drop per load lead: 2 VDC
* Cosmetic Condition: Very Good
* Working Condition: Operationally Verified
* Warranty: Rest assured that your purchase includes a 3-day DOA Guarantee. If the item is DOA, you will need to notify us within 3-days of receipt. Item(s) must be returned in the same condition as received within 7 days of receipt. (See below for further details).
We strongly recommend that you properly pack and insure the package against loss or damage. It is ultimately your responsibility that your returned product arrives at our location within the allotted return time frame in the same condition it was sent.
