Burr oak fp-2 fin press
BURR OAK MODEL FP-2 STRAIGHT SIDE, HIGH-SPEED, FLYWHEEL DESIGN, DOUBLE CRANK
FIN PRESS*
Capacity: 60 Ton
Stroke: 1-1/2"
Shut Height (SDAU): 9" - 12" (Over 3-7/8" Bolster)
Withdrawal Travel (Hydraulic): 9" - 13"
Bed Area: 48" L-R x 34" F-B
Slide Face Area: 48" L-R x 30" F-B
Opening in Bed: 38" L-R x 10" F-B
Window Openings: 20.5" W
Speed (Variable): 100 - 300 SPM
Air Clutch and Brake with Selector Controls
8-Point Gibbing
Tie Rod Construction
EQUIPPED WITH:
Direct Drive Feed System (Rear to Front)
Decoiler
Hydraulic Overload Protection
Hydraulic Withdrawal (Raise & Lower) of Crown & Ram
Bolster Plate (3-7/8" Thick)
Automatic Lubrication System
(2) Spring Ram Counterbalances
AC Main Drive Motor w/Mechanical Vari-Speed
Electrical Controls (Seperate Panel)
Dual Palm Button Operation
Hydraulic Power Unit (Seperate, Free-Standing)
Approximate Overall Dimensions: 95" L-R x 60" F-B x 112" H
Approximate Weight: 18,000 Lbs.(FEEDER: 96"X 60"X 52"H)
(HYDR.: 33"X 21"X 21"H)
Serial Number: FP2-48-1019 (New 1987)
P2 F.O.B. Elk Grove, IL - $ 89,500.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
