Tektronix CMD80 in great working condition cmd 80
This unit has ALL OPTIONS installed:
* CMD-B1 - High-stability reference oscillator
* CMD-B3 - Multireference frequency Inputs/Outputs
* CMD-B14 - 13k vocoder rate (14.4k data rate)
* CMD-B60 - Adapter for B61 and B62
* CMD-B61 - IEEE Bus Interface
* CMD-B62 - Memory Card Interface
* CMD-B81 - Additive White Gaussian Noise (AWGN) generator
* CMD-B84 - IS-136 (D-AMPS) Test Capabilities
* CMD-K1 - Adds cellular operation
* CMD-K2 - Adds PCS operation
Precise high-speed measurements on CDMA, TDMA and analog mobiles for use in production, quality assurance, service and development.
Additional capability continues to be added to the proven CMD80 platform. In addition to CDMA, AMPS (N-AMPS) and TACS (J/N/E-TACS), digital AMPS (IS-136) measurements on mobile stations are now possible with option B84. CMD80 is thus able to support all multiple access methods presently used in mobile communications (FDMA, CDMA, TDMA) on a single hardware platform.
This unit has the following features:
* High measurement accuracy and repeatability
* High reliability and quality
* Triple mode (CDMA, TDMA, Analog) dual band (cellular, PCS) in one box
* Remote control via IEEE488/IEC625 bus
* Autotest - complete mobile testing at a keystroke
* Remote control via GPIB or RS232
* Suitable for production, development and service
* Very fast remote control operation
* Voice lookback and comprehensive testing of mobiles
* Powerful signaling capabilities
* Simple interactive operation
